Stomp Z3-140 Pit Bike 2026
£1,099.00
or 3 payments of £366.33 with Klarna
Hurry, only 1 left in stock!
Off-road use only. Not road legal. Ride on private land with the landowner's permission. Read more
-
Description
2026 Stomp Z3-140 Pit Bike – Quick Overview
Best for: confident riders progressing onto a powerful 140cc manual pit bike.
Engine: oil-cooled YX140 with Z40 race cam.
Power: 8.2kW at 8,000 RPM.
Gearbox: 4-speed manual, N-1-2-3-4.
Wheels: 14-inch front / 12-inch rear with SDG hubs.
Seat height: 820mm.
Why riders choose it: strong 140cc performance, oil cooling, hydraulic disc brakes and a proven manual pit bike layout.
Our view: a serious step-up pit bike for riders wanting capable 140cc performance without moving to the more race-focused Z3R-140.
The 2026 Stomp Z3-140 is a capable 140cc manual pit bike built for confident riders who want strong petrol performance, proper clutch control and a dependable off-road setup.
Powered by an oil-cooled YX140 engine with a Z40 race cam, the Z3-140 produces 8.2kW at 8,000 RPM and 10.2Nm of torque at 7,500 RPM.
Its four-speed manual gearbox, lightweight steel spine frame, 14/12-inch wheel setup and hydraulic disc brakes make it a strong choice for riders progressing from smaller or less powerful pit bikes.
With an 820mm seat height, upgraded PRO footpegs, alloy fat handlebars and adjustable rear shock preload, the Z3-140 delivers a substantial step up in capability while retaining a straightforward, familiar pit bike layout.
For riders wanting an even more race-focused chassis and suspension package, the Stomp Z3R-140 Race sits above the standard model in the range.
My Take as a British MX Rider
The standard Z3-140 is a really sensible option for someone who wants a proper 140cc pit bike without necessarily needing the full race-focused package of the Z3R.
The YX140 engine with Z40 race cam gives it plenty of usable performance, and the four-speed manual gearbox makes it a great bike for developing clutch control, gear selection and riding technique.
I particularly like the combination of 14/12-inch wheels, hydraulic brakes and an 820mm seat height. It's a capable setup for riders who are already comfortable on smaller pit bikes and want something more substantial.
It doesn't have the same chassis and suspension specification as the Z3R Race, but not every rider needs that additional equipment.
If you're confident riding a manual pit bike and want strong 140cc performance for recreational off-road riding, the standard Z3-140 is a very good option.
Helpful Pit Bike Buying Guides
Best Pit Bike for Beginners
Find the right first petrol pit bike. Pit Bikes for 8–10 Year Olds
Compare smaller progression bikes. Pit Bikes for 10–12 Year Olds
Explore options for developing riders. Stomp Pit Bikes
Browse the Stomp range. Manual Pit Bikes
Bikes for riders developing clutch control. All Pit Bikes
Shop the full Garland range.
Why Upgrade to the 2026 Stomp Z3-140?
The Z3-140 is a substantial progression from smaller beginner-focused pit bikes, offering a 140cc engine, full manual transmission and larger 14/12-inch wheels.
Feature Smaller Beginner Pit Bikes Stomp Z3-140 Engine Typically 70cc–125cc 140cc YX140 with Z40 race cam Transmission Automatic, semi-automatic or manual 4-speed manual with clutch Wheels Often smaller wheel combinations 14-inch front / 12-inch rear Suspension Basic fork and shock setups 735mm USD forks and 290mm piggyback shock Best For Learning and early progression Confident riders wanting stronger performance The Z3-140 is a good step up when the rider has already developed the confidence and experience needed to manage a larger, more powerful manual pit bike.
Why Choose the Stomp Z3-140?
YX140 Oil-Cooled Engine
140cc four-stroke engine with Z40 race cam, delivering 8.2kW at 8,000 RPM.
4-Speed Manual Gearbox
Full clutch and gear control with an N-1-2-3-4 shift pattern.
14/12-Inch Wheels
Steel rims with SDG hubs and off-road tyres for a familiar pit bike setup.
Hydraulic Disc Brakes
210mm front and 180mm rear wavy discs for responsive braking.
Piggyback Rear Shock
290mm rear shock with adjustable spring preload to help tailor the setup.
Upgraded Components
PRO footpegs, alloy fat handlebars and a 32mm big-bore exhaust with power bomb muffler.
Where Does the Stomp Z3-140 Fit in the Range?
The standard Z3-140 is designed for riders who want a capable 140cc manual pit bike, while the Z3R-140 is aimed at those looking for a more race-focused chassis and suspension package.
Stomp Z3-140 StandardStomp Z3R-140 Race
Strong 140cc manual performance for confident off-road riders.
A more race-focused chassis and suspension package. Manual Pit Bikes
Compare other clutch-operated pit bikes.
Is the Stomp Z3-140 Right for Your Rider?
Choose the Z3-140 If...
- The rider is confident on petrol pit bikes
- They understand manual clutch and gearbox operation
- You want strong 140cc performance
- A 14/12-inch wheel setup suits their height
- You want a capable recreational off-road pit bike
- You don't need the more race-focused Z3R chassis
Consider a Smaller Bike If...
- This is the rider's first petrol bike
- They are still learning clutch control
- The 820mm seat height is too tall
- The 71kg dry weight is difficult to manage
- A smaller, less powerful engine would be more appropriate
Stomp Z3-140 Rider Sizing Guide
Important: choose a pit bike based on the rider's height, strength, confidence and riding experience rather than age alone.
With an 820mm seat height, 71kg dry weight and 140cc manual engine, the Z3-140 is best suited to riders who can comfortably manage its size and power.
Best For Confident riders progressing to 140cc manual pit bikes Experience Level Intermediate / experienced Seat Height 820mm / 82cm Dry Weight 71kg Wheel Size 14-inch front / 12-inch rear Ground Clearance 280mm If you're unsure whether a 140cc manual bike is the right choice, take a look at our Best Pit Bike for Beginners UK guide.
Stomp Z3-140 vs Z3R-140 Race: Which Should You Choose?
Both models sit in the 140cc category, but the standard Z3-140 and Z3R-140 Race are aimed at slightly different riding requirements.
Feature Z3-140 Standard Z3R-140 Race Engine YX140 with Z40 race cam SR140C with Z40 race cam Frame Lightweight steel spine frame SDG2 heavy-duty cradle frame Front Forks 735mm USD, non-adjustable 735mm CNC USD Rear Shock 290mm piggyback, preload-adjustable 290mm nitrogen piggyback Wheels 14/12-inch SDG hubs 14/12-inch SDG steel wheels Best For Confident recreational off-road riders More race-focused riding and track use Choose the Stomp Z3-140 Standard if you want a strong 140cc manual pit bike with capable suspension and braking equipment for recreational off-road riding.
Choose the Stomp Z3R-140 Race if you want the more race-focused chassis and suspension specification for harder track-style riding.
YX140 Engine, Manual Gearbox & Riding Performance
The Stomp Z3-140 uses a 140cc YX four-stroke engine with a Z40 race cam and oil cooling.
Producing 8.2kW at 8,000 RPM and 10.2Nm at 7,500 RPM, it offers strong performance for a compact off-road pit bike.
A 26mm carburettor supplies the engine, while the CDI ignition and kick-start system provide a straightforward mechanical setup.
The four-speed manual gearbox uses an N-1-2-3-4 shift pattern, giving the rider direct control over clutch engagement, gear selection and engine performance.
The 32mm big-bore exhaust and power bomb muffler complete the engine package.
What's in the Box?
- 2026 Stomp Z3-140 pit bike
- Components required for final assembly, as supplied by the manufacturer
When ordered boxed, the bike requires final assembly, mechanical setup and safety checks before riding.
Assembly should be carried out by a mechanically competent person. Always check engine oil, brakes, chain tension, controls, wheel fixings and other safety-critical components before use.
2026 Stomp Z3-140 Technical Specifications
Below are the manufacturer's supplied specifications for the standard 2026 Stomp Z3-140.
Engine & Transmission Manufacturer Stomp Model Z3-140 Engine YX140 with Z40 Race Cam, oil cooled Valves SOHC, 2 valve Displacement 140.0cc Bore x Stroke 56 x 57mm Compression Ratio 9.8:1 Fuel System 26mm carburettor Maximum Power 8.2kW @ 8,000 RPM Maximum Torque 10.2Nm @ 7,500 RPM Clutch Wet, 5 disc Ignition CDI Starting Kick start Transmission 4-speed manual, N-1-2-3-4 Final Drive 420 chain Frame & Components Frame Lightweight steel spine frame Rear Subframe CRF70 subframe Swingarm 430mm steel Footpegs Upgraded PRO footpegs Handlebars New alloy fat bar Exhaust 32mm big bore Muffler Power bomb Suspension, Wheels & Brakes Front Suspension 735mm USD forks, non-adjustable Rear Suspension 290mm piggyback shock, adjustable preload Front Rim 14-inch steel rim with SDG hub Rear Rim 12-inch steel rim with SDG hub Rim Lock Rear Front Tyre 60/100-14 Rear Tyre 80/100-12 Front Brake Hydraulic, 210mm wavy disc Rear Brake Hydraulic, 180mm wavy disc Dimensions & Capacity Wheelbase 1240mm Ground Clearance 280mm Seat Height 820mm Dry Weight 71kg Fuel Capacity 5.5 litres Wheel Size 14/12 Packing Size 1560 x 380 x 735mm Warranty 6 months parts only
Warehouse Stock & Fast UK Delivery
Online-Only Specialist Pit Bike Retailer
Garland Powersports is an online-only UK retailer specialising in electric bikes, petrol pit bikes and youth off-road machines.
We offer UK-wide delivery on the Stomp pit bike range, with availability shown on the product page.
Boxed delivery: the best-value option for customers who are comfortable arranging final assembly and mechanical checks.
Built and PDI checked: where offered at checkout, we can arrange for your pit bike to be assembled, checked and prepared before delivery.
Please check the available delivery options and estimated timescales at checkout.
Frequently Asked Questions
Is the Stomp Z3-140 suitable for beginners?
The Z3-140 is better suited to riders with previous petrol pit bike experience. Its 140cc engine, manual clutch and 820mm seat height make it less suitable as a first bike for an inexperienced rider.
What engine does the 2026 Stomp Z3-140 use?
It uses an oil-cooled YX140 four-stroke engine with a Z40 race cam.
How much power does the Stomp Z3-140 produce?
The manufacturer specifies 8.2kW at 8,000 RPM, with maximum torque of 10.2Nm at 7,500 RPM.
Is the Stomp Z3-140 manual?
Yes. It has a four-speed manual gearbox with a wet five-disc clutch and an N-1-2-3-4 shift pattern.
What is the seat height?
The Stomp Z3-140 has an 820mm (82cm) seat height.
How much does the Z3-140 weigh?
The manufacturer's specified dry weight is 71kg.
What size wheels does it have?
The Z3-140 uses a 14-inch front wheel and 12-inch rear wheel with steel rims and SDG hubs.
Does the Stomp Z3-140 have adjustable suspension?
The rear 290mm piggyback shock has adjustable preload. The 735mm upside-down front forks are non-adjustable.
What's the difference between the Stomp Z3-140 and Z3R-140?
The standard Z3-140 uses a YX140 engine and lightweight steel spine frame. The Z3R-140 Race uses an SR140C engine and a more race-focused SDG2 heavy-duty cradle chassis and suspension package.
Is the Stomp Z3-140 road legal?
No. This is an off-road pit bike, not a road-registered motorcycle. It should only be ridden where lawful permission and appropriate facilities are available.
Does the bike need assembly?
If ordered boxed, yes. Final assembly, setup and mechanical safety checks are required before riding. Built and PDI-checked options may be available at checkout.
What warranty does the Stomp Z3-140 have?
The manufacturer specifies a six-month parts-only warranty, subject to the applicable warranty terms.
Our Verdict
Choose the Stomp Z3-140 Standard if you're looking for a capable 140cc manual pit bike with strong performance, 14/12-inch wheels and a practical off-road setup.
Choose the Stomp Z3R-140 Race if you want a more race-focused chassis and suspension package for harder track-style riding.
Choose a smaller pit bike if the rider is still learning clutch control or would benefit from a lighter, less powerful machine.
For confident riders wanting a proper 140cc manual pit bike, the 2026 Stomp Z3-140 offers an excellent combination of performance, specification and practicality.
Related Pit Bike Guides
Best Pit Bike for Beginners
Compare suitable first petrol pit bikes. Pit Bikes for 8–10 Year Olds
Explore smaller progression options. Pit Bikes for 10–12 Year Olds
Find suitable step-up bikes. Stomp Pit Bikes
Browse the complete Stomp range. Manual Pit Bikes
Compare clutch-operated petrol bikes. All Pit Bikes
Shop Garland's complete pit bike range.Ready to Choose the 2026 Stomp Z3-140?
The Stomp Z3-140 combines a 140cc oil-cooled engine, four-speed manual transmission, 14/12-inch wheels and hydraulic disc brakes in a capable off-road package.
Order online from Garland Powersports with UK-wide delivery available.
-
